External Dimensions (in) Hover me Nominal external dimensions (LxWxH). Features (flanges, feet, bosses, etc.) may increase the overall dimensions. Refer to drawings/models for exact dimensional details. | 11.81 x 9.05 x 3.40 in |
External Dimensions (mm) | 300 x 230 x 86 mm |
Internal Dimensions (in) Hover me Nominal internal dimensions (LxWxH). Features (screw towers, mounting bosses, corner radii, wall draft, etc.) may impact the overall dimensions. Refer to drawings/models for exact dimensional details. | 11.50 x 8.75 x 3.13 in |
Internal Dimensions (mm) | 292 x 222 x 80 mm |
Wall Thickness Hover me Nominal wall thickness. Wall thickness may vary throughout the enclosure. Refer to drawings/models for exact details. | 0.129 in |
Weight | 2.26 lbs |
2d Drawing PDF | Download 2D Drawing PDF |
Download Material Specs | Download Material Specs |
Base | Polycarbonate |
Cover | Polycarbonate |
Gasket | Silicone |
Assembly Screws | Stainless steel |
Application | Outdoor use |
UV Resistant | Yes |
Waterproof | Yes |
3D Model | WC-42 STEP |
2D Drawing DWG | WC-42 DWG |
2D Drawing PDF | WC-42 PDF |
Other Files | WC-42 Printing Template |
WC & WP Series Material Specs | Polycarbonate Specs |
Internal Mounting Panel | WX-46 |
Adhesive PCB Mounting Standoffs | MB-01-20 |
Cable Management & Venting Accessories | Cable Glands & Vents |
Surface Mounting Kit | WP-90 |
